Hello! I found this project in my tutorial folder. I started it over a year ago and got distracted with work and thought it’d be good to complete. This is another way to model a pillowed form that has a corner and runs into a planar face. Similar to housings found on various goods. I think this technique is better than my MK1 and MK2 techniques, as it allows a much tighter corner to be used, with less chance of wrinkles or wobbly curvature in the surface that radiates out from the corner.
Solidworks: MK3 Pillowed Form/Corner
- Post author:Andrew
- Post published:July 14, 2022
- Post category:CAD Sculpting / Solidworks tutorials
Tags: AJ Design Studio, CAD sculpting, Digital Sculpting, Pillowed Form, Solidworks Surfacing, Surfacing
